With the new L6 paint shop, the Motherson company SMP in Neustadt an der Donau, Germany is building a reference plant according to the latest Industry 4.0 standard.
Motherson manufactures plastic parts and highly integrated modules for the automotive industry. The automatic painting plant is being planned and installed turnkey by ASIS GmbH from Landshut as general contractor. “For more than 22 years a business partnership connects us with SMP. The order for the new L6 is a milestone in the cooperation, which we will deliver in top quality as usual,” says ASIS CEO Hans-Jürgen Multhammer. Also on board is Wenker GmbH & Co. KG from Ahaus near Münster, Germany, which will supply parts of the plant technology. Due to the high value-added shares of their scope of supply, both partners complement each other extremely well.
Basic Plant Data
In the L6 painting line, plastic parts for the automotive industry are coated high quality. The solvent plant includes the areas pretreatment, water dryer, flaming booth, primer booth, base coat booth, clear coat booth, clear coat dryer, paint supply with high runner systems as well as piggable special paint systems. The application is carried out by robots from the manufacturer ABB. All booths operate in line tracking mode: the product carriers move past the robots while they apply. All robot booths are easily accessible to personnel via a central clean room. A skid conveyor system in combination with lifting and lowering stations moves the workpieces through the three levels of the plant. Assembly will start in the summer of 2022. “Regardless of whether flame treatment, paint supply or application – in all areas we can use our own products, which are already successfully used in many plants. Here we can look back on a great amount of application experience,” says Multhammer.
Solvent vs. Water-based Paint
Since the entry of water-based paints, they have been considered an environmentally friendly alternative to solvent-based paints. At first glance, water-based coatings sound like the greener and therefore better solution. But if you take a closer look at the entire process, including the required plant technology and the associated energy consumption, the situation quickly changes. Compared to solvent systems, water-based coating systems require two additional dryers with associated cooling zones. In addition to the plant costs, this also significantly increases the energy consumption of a water-based painting line. In practice, the exhaust air from water-based coating systems often have to be re-fired with gas, while the solvent concentration in solvent plants is usually sufficient for autothermal operation of the afterburning system. If you calculate the energy requirements of both types of plant, the solvent plant is significantly more energy-efficient than its water-based counterpart. In terms of investment costs, running costs and environmental footprint, the solvent plant is therefore the more sustainable and efficient plant type for the project in Neustadt.
